GZY-N4129
UHF Extreme RFID Tags
It is made of PEEK high-end engineering plastic, with dimensions of 41×29mm. It can withstand temperatures up to 300℃ and has a protection level of IP68/IP69. The farthest reading distance on the metal surface is 6.5 meters. The structure is sturdy and is specially designed for extreme high-temperature, high-pressure, and strong acid-base environments (such as energy pipelines).
/
High-Temperature RFID Tags
Features
-
Full pH Range Resistance (0-14) -
Maximum 6.5 Meters -
IP68/IP69 Protection Rating -
High-Temperature PEEK Material -
300℃ Temperature Resistance -
Secure 4-Hole Screw Mounting
Specifications
-
RFID Features:
RFID Protocol: EPC Class1 Gen2, ISO18000-6C
Frequency: (US) 902-928MHz, (EU) 865-868MHz
Chip Type: NXP Ucode 8, 9
Memory : EPC 96bits-128bits , USER 0bits, TID64bits
TID Memory: 64bit
Date Storage: >10years
Re-Write: 100,0000 times Read Range : (Fix Reader) 1-6.5m, On metal
Read Range : (Handheld Reader) 1-3.5m, On metal
-
Physical Features:
Size 41.0x29.0mm, Hole: D2.3mmx4
Material: PEEK
Chip Type NXP Ucode 8, 9
Colour: Black
Mounting Methods: Screw - Socket head cap screw(M2)
Weight: 15.0g
-
Environmental Features:
IP Rating IP68
Storage Temperature: -55°C to +200°C (280°С for 50 minutes, 250°С for 150minutes)
Withstand PH:
Operation Temperature: -40°C to +150°C (working 10hours in 180°С)
