GZY-CT3
RFID wall-mounted access control reader
Ultra-thin wall-mounted design, with a thickness of only 45mm. It supports infrared triggering and entry/exit counting, with a reading range of 0-2 meters.Suitable for scenarios such as narrow passages and access control, featuring low false reading rate and sound and light alarm functions. Easy to install.
/
RFID wall-mounted access control reader
Features
-
High Multi-Tag Read Rate, Low Missed Reads -
In/Out People Counting Supported -
Audible & Visual Anti-Theft Alarm -
ISO 18000-6C Standard -
Compact Space-Saving Design -
Infrared Triggered Auto-Sensing
Specifications
-
RFID Performance
RFID Frequency 865-868Mhz /902-928Mhz(customized) Air Interface Protocol EPC global UHF Class 1 Gen 2 / ISO 18000-6C Reader Chip IMPINJ E710 RF Output 0-30dBm(adjustable) Reading Distance 0-2m(adjustable) Inventory Tag Peak Speed > 700 Pcs/Second
Alarm LED Indicator Way of Working Automatic mode, trigger mode, interactive mode, etc. Antennas 4 SMA antenna ports, 7dbi circular polarization antenna System Support Windows / Android (optional)
Communication Interface TCP/IP、RS232、optional 4G/WiFi Hardware N29 CPU, 2G RAM, 32G ROM,RK3288 CPU, 2G RAM, 8G ROM (optional)
Application Software interface(SDK) Provide with API SDK and C#, Java application routines Output Power Accuracy +/- 1dB
Input Power Accuracy +/- 0.2dB -
Physical Performance
Dimensions 1770mm*45mm*180mm
Power Supply AC110-220V 50Hz 150W Metrial Carbon steel plate Humidity 5% to 95%, non-condensing
Operating Temp. -10℃ to +60℃ Storage Temp. -20℃ to +70℃ Weight 25KG
Applications
